LED 조명 - COB, 엔진, 모듈, 스트립

제조업체 부품 번호	재고 상태	가격	수량	데이터시트	Packaging	Series	ProductStatus	Type	Color	CCT(K)	Wavelength	Configuration	LuminousFlux@Current/Temperature	Current-Test	Temperature-Test	Voltage-Forward(Vf)(Typ)	Lumens/Watt@Current-Test	Current-Max	CRI(ColorRenderingIndex)	ViewingAngle	Features	Size/Dimension	Height	LightEmittingSurface(LES)
CXA2590-0000-000R0YX227F LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	2,898	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	2700K 4-Step MacAdam Ellipse	-	Square	5800lm (5590lm ~ 6010lm)	1.2A	85°C	69V	70 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YX227H LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	2,602	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	2700K 2-Step MacAdam Ellipse	-	Square	5800lm (5590lm ~ 6010lm)	1.2A	85°C	69V	70 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YX230F LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	2,315	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	3000K 4-Step MacAdam Ellipse	-	Square	5800lm (5590lm ~ 6010lm)	1.2A	85°C	69V	70 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YX230H LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	3,770	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	3000K 2-Step MacAdam Ellipse	-	Square	5800lm (5590lm ~ 6010lm)	1.2A	85°C	69V	70 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YX427F LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	3,905	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	2700K 4-Step MacAdam Ellipse	-	Square	6220lm (6010lm ~ 6430lm)	1.2A	85°C	69V	75 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YX427H LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	2,215	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	2700K 2-Step MacAdam Ellipse	-	Square	6220lm (6010lm ~ 6430lm)	1.2A	85°C	69V	75 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YX430F LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	3,362	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	3000K 4-Step MacAdam Ellipse	-	Square	6220lm (6010lm ~ 6430lm)	1.2A	85°C	69V	75 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YX430H LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	2,162	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	3000K 2-Step MacAdam Ellipse	-	Square	6220lm (6010lm ~ 6430lm)	1.2A	85°C	69V	75 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YX435F LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	2,726	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	3500K 4-Step MacAdam Ellipse	-	Square	6220lm (6010lm ~ 6430lm)	1.2A	85°C	69V	75 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YX435H LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	3,141	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	3500K 2-Step MacAdam Ellipse	-	Square	6220lm (6010lm ~ 6430lm)	1.2A	85°C	69V	75 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YY227F LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	3,530	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	2700K 4-Step MacAdam Ellipse	-	Square	6670lm (6430lm ~ 6910lm)	1.2A	85°C	69V	81 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YY227H LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	2,226	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	2700K 2-Step MacAdam Ellipse	-	Square	6670lm (6430lm ~ 6910lm)	1.2A	85°C	69V	81 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YY230F LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	2,539	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	3000K 4-Step MacAdam Ellipse	-	Square	6670lm (6430lm ~ 6910lm)	1.2A	85°C	69V	81 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YY230H LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	2,017	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	3000K 2-Step MacAdam Ellipse	-	Square	6670lm (6430lm ~ 6910lm)	1.2A	85°C	69V	81 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YY235F LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	2,470	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	3500K 4-Step MacAdam Ellipse	-	Square	6670lm (6430lm ~ 6910lm)	1.2A	85°C	69V	81 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA2590-0000-000R0YY235H LED COB CXA2590 WARM WHT SQUARE CreeLED, Inc.	2,296	-	RFQ	데이터시트	Tray	XLamp® CXA2590	Obsolete	Chip On Board (COB)	White, Warm	3500K 2-Step MacAdam Ellipse	-	Square	6670lm (6430lm ~ 6910lm)	1.2A	85°C	69V	81 lm/W	1.8A	93	115°	-	23.85mm L x 23.85mm W	1.55mm	19.00mm Dia
CXA1850-0000-000N0HX250F LED COB CXA1850 COOL WHT SQUARE CreeLED, Inc.	2,072	-	RFQ	데이터시트	Tray	XLamp® CXA1850	Obsolete	Chip On Board (COB)	White, Cool	5000K 4-Step MacAdam Ellipse	-	Square	5800lm (5590lm ~ 6010lm)	1.4A	85°C	35V	118 lm/W	2.1A	80	115°	-	17.85mm L x 17.85mm W	1.55mm	12.00mm Dia
LMH020-8000-30G9-00000TW LED MOD 8000LM 3000K FLAT CreeLED, Inc.	3,473	-	RFQ	데이터시트	Box	LMH2 TrueWhite®	Obsolete	LED Module	White, Warm	3000K	-	Round	8000lm (Typ)	2A	-	46.2V	85 lm/W	2.1A	90	84°	Dimming - WhiteLight	88.20mm Dia	30.00mm	-
LMH020-8000-35G9-00000TW LED MOD 8000LM 3500K FLAT CreeLED, Inc.	3,150	-	RFQ	데이터시트	Box	LMH2 TrueWhite®	Obsolete	LED Module	White, Warm	3500K	-	Round	8000lm (Typ)	2A	-	46.2V	85 lm/W	2.1A	90	110°	Dimming - WhiteLight	88.20mm Dia	30.00mm	-
XQERED-SB-0000-000000501 LED MODULE XLAMP RED STARBOARD CreeLED, Inc.	3,124	-	RFQ	데이터시트	Tray	XLamp® XQ-E	Discontinued at Mosen	LED Module	Red	-	625nm	Starboard	57lm (Typ)	350mA	25°C	2.2V	74 lm/W	1A	-	130°	-	-	1.58mm	-
