전력 릴레이, 2암페어 이상
| 사진: | 제조업체 부품 번호 | 재고 상태 | 가격 | 수량 | 데이터시트 | Packaging | Series | ProductStatus | MountingType | CoilVoltage | ContactForm | ContactRating(Current) | SwitchingVoltage | CoilCurrent | CoilType | Features | TerminationStyle | SealRating | CoilInsulation | MustOperateVoltage | MustReleaseVoltage | OperateTime | ReleaseTime | OperatingTemperature | ContactMaterial |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
G8P-1A4TP DC110RELAY GEN PURPOSE SPST 30A 110V Omron Electronics Inc-EMC Div |
3,677 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 110VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 9 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | Sealed - Fully | Class F | 82.5 VDC | 11 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P1A4TPDC18RELAY GEN PURPOSE SPST 30A 18V Omron Electronics Inc-EMC Div |
2,854 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 18VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 50 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | Sealed - Fully | Class F | 13.5 VDC | 1.8 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1A4TP DC22RELAY GEN PURPOSE SPST 30A 22V Omron Electronics Inc-EMC Div |
3,239 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 22VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 41 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | Sealed - Fully | Class F | 16.5 VDC | 2.2 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1A4TP DC48RELAY GEN PURPOSE SPST 30A 48V Omron Electronics Inc-EMC Div |
3,632 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 48VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 19 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | Sealed - Fully | Class F | 36 VDC | 4.8 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1A4TP DC5RELAY GEN PURPOSE SPST 30A 5V Omron Electronics Inc-EMC Div |
2,444 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 5VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 185 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | Sealed - Fully | Class F | 3.75 VDC | 0.5 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1A4TP DC9RELAY GEN PURPOSE SPST 30A 9V Omron Electronics Inc-EMC Div |
3,323 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 9VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 93 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | Sealed - Fully | Class F | 6.75 VDC | 0.9 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1A4TP-V DC24RELAY GEN PURPOSE SPST 30A 24V Omron Electronics Inc-EMC Div |
3,282 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 24VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 36 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | Sealed - Fully | Class F | 18 VDC | 2.4 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1A4TP-V DC9RELAY GEN PURPOSE SPST 30A 9V Omron Electronics Inc-EMC Div |
2,442 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 9VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 93 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | Sealed - Fully | Class F | 6.75 VDC | 0.9 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
G8P-1AP DC110RELAY GEN PURPOSE SPST 30A 110V Omron Electronics Inc-EMC Div |
2,364 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 110VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 9 mA | Non Latching | - | PC Pin | - | Class F | 82.5 VDC | 11 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1AP DC48RELAY GEN PURPOSE SPST 30A 48V Omron Electronics Inc-EMC Div |
2,493 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 48VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 19 mA | Non Latching | - | PC Pin | - | Class F | 36 VDC | 4.8 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1AP DC9RELAY GEN PURPOSE SPST 30A 9V Omron Electronics Inc-EMC Div |
3,374 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 9VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 93 mA | Non Latching | - | PC Pin | - | Class F | 6.75 VDC | 0.9 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1AP-FD DC48RELAY GEN PURPOSE SPST 30A 48V Omron Electronics Inc-EMC Div |
3,389 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 48VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 19 mA | Non Latching | - | PC Pin | - | Class F | 36 VDC | 4.8 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Tin Indium (AgSnIn) |
|
G8P-1ATP DC110RELAY GEN PURPOSE SPST 30A 110V Omron Electronics Inc-EMC Div |
2,824 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 110VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 9 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | - | Class F | 82.5 VDC | 11 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1ATP DC12RELAY GEN PURPOSE SPST 30A 12V Omron Electronics Inc-EMC Div |
3,955 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 12VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 77 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | - | Class F | 9 VDC | 1.2 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1ATP DC24RELAY GEN PURPOSE SPST 30A 24V Omron Electronics Inc-EMC Div |
3,303 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 24VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 36 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | - | Class F | 18 VDC | 2.4 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1ATP DC48RELAY GEN PURPOSE SPST 30A 48V Omron Electronics Inc-EMC Div |
2,649 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 48VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 19 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | - | Class F | 36 VDC | 4.8 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1ATP DC5RELAY GEN PURPOSE SPST 30A 5V Omron Electronics Inc-EMC Div |
3,338 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 5VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 185 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | - | Class F | 3.75 VDC | 0.5 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1ATP DC9RELAY GEN PURPOSE SPST 30A 9V Omron Electronics Inc-EMC Div |
2,740 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Through Hole | 9VDC | SPST-NO (1 Form A) | 30 A | 250VAC, 28VDC - Max | 93 mA | Non Latching | - | PC Pin, Quick Connect - 0.250 (6.3mm) | - | Class F | 6.75 VDC | 0.9 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
G8P-1C2T-F DC110RELAY GEN PURPOSE SPDT 10A 110V Omron Electronics Inc-EMC Div |
3,688 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Chassis Mount | 110VDC | SPDT (1 Form C) | 10 A | 250VAC, 28VDC - Max | 9 mA | Non Latching | - | Quick Connect - 0.187/0.250 | - | Class F | 82.5 VDC | 11 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
|
|
G8P-1C2T-F DC48RELAY GEN PURPOSE SPDT 10A 48V Omron Electronics Inc-EMC Div |
2,218 | - |
RFQ |
데이터시트 |
Bulk | G8P | Obsolete | Chassis Mount | 48VDC | SPDT (1 Form C) | 10 A | 250VAC, 28VDC - Max | 19 mA | Non Latching | - | Quick Connect - 0.187/0.250 | - | Class F | 36 VDC | 4.8 VDC | 15 ms | 10 ms | -55°C ~ 105°C | Silver Cadmium Oxide (AgCdO) |
