LED 조명 - COB, 엔진, 모듈, 스트립

제조업체 부품 번호	재고 상태	가격	수량	데이터시트	Packaging	Series	ProductStatus	Type	Color	CCT(K)	Wavelength	Configuration	LuminousFlux@Current/Temperature	Current-Test	Temperature-Test	Voltage-Forward(Vf)(Typ)	Lumens/Watt@Current-Test	Current-Max	CRI(ColorRenderingIndex)	ViewingAngle	Features	Size/Dimension	Height	LightEmittingSurface(LES)
CHM-27-40-80-36-AB00-F2-3 LED COB Luminus Devices Inc.	3,580	-	RFQ	데이터시트	Tray	CHM-27	Not For New Designs	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	10985lm (Typ)	2.7A	85°C	35V	116 lm/W	4A	80	120°	-	31.50mm L x 31.50mm W	1.37mm	26.50mm Dia
CHM-27-40-90-36-AB00-F2-3 LED COB Luminus Devices Inc.	3,188	-	RFQ	데이터시트	Tray	CHM-27	Not For New Designs	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	9470lm (Typ)	2.7A	85°C	35V	100 lm/W	4A	90	120°	-	31.50mm L x 31.50mm W	1.37mm	26.50mm Dia
CHM-27-50-70-36-AB00-F2-5 LED COB Luminus Devices Inc.	3,199	-	RFQ		Tray	CHM-27	Not For New Designs	Chip On Board (COB)	White, Cool	5000K 5-Step MacAdam Ellipse	-	Square	11810lm (Typ)	2.7A	85°C	35V	125 lm/W	4A	70	120°	-	31.50mm L x 31.50mm W	1.37mm	26.50mm Dia
CHM-27-50-80-36-AB00-F2-5 LED COB Luminus Devices Inc.	2,430	-	RFQ		Tray	CHM-27	Not For New Designs	Chip On Board (COB)	White, Cool	5000K 5-Step MacAdam Ellipse	-	Square	11430lm (Typ)	2.7A	85°C	35V	121 lm/W	4A	80	120°	-	31.50mm L x 31.50mm W	1.37mm	26.50mm Dia
CHM-27-65-70-36-AB00-F2-5 LED COB Luminus Devices Inc.	2,552	-	RFQ		Tray	CHM-27	Not For New Designs	Chip On Board (COB)	White, Cool	6500K 5-Step MacAdam Ellipse	-	Square	11760lm (Typ)	2.7A	85°C	35V	124 lm/W	4A	70	120°	-	31.50mm L x 31.50mm W	1.37mm	26.50mm Dia
CHM-27-65-80-36-AB00-F2-5 LED COB Luminus Devices Inc.	3,473	-	RFQ		Tray	CHM-27	Not For New Designs	Chip On Board (COB)	White, Cool	6500K 5-Step MacAdam Ellipse	-	Square	11200lm (Typ)	2.7A	85°C	35V	119 lm/W	4A	80	120°	-	31.50mm L x 31.50mm W	1.37mm	26.50mm Dia
SFT-20-CG-R35-MPC LED Luminus Devices Inc.	2,600	-	RFQ	데이터시트	Tray	SFT-20	Active	Chip On Board (COB)	Green	-	555nm	Starboard	520lm (Typ)	1.4A	25°C	3V	124 lm/W	6A	-	-	-	19.90mm Dia	1.80mm	1.60mm L x 1.30mm W
CVM-14-31-95-36-AA00-F2-2 LED COB WHT 3100K 95CRI Luminus Devices Inc.	2,956	-	RFQ	데이터시트	Tray	XNova™ Studio	Active	Chip On Board (COB)	White, Warm	3000K 2-Step MacAdam Ellipse	-	Square	-	1A	-	36V	-	1A	95	120°	-	19.00mm L x 19.00mm W	1.37mm	13.50mm Dia
CVM-14-56-95-36-AA00-F2-2 LED COB WHT 5600K 95CRI Luminus Devices Inc.	2,208	-	RFQ	데이터시트	Tray	XNova™ Studio	Active	Chip On Board (COB)	White, Cool	5600K 2-Step MacAdam Ellipse	-	Square	-	1A	-	36V	-	1A	95	120°	-	19.00mm L x 19.00mm W	1.37mm	13.50mm Dia
CHM-27-50-80-36-AA00-F2-3 LED COB CHM27 COOL WHITE SQUARE Luminus Devices Inc.	3,867	-	RFQ	데이터시트	Tray	CHM-27	Active	Chip On Board (COB)	White, Cool	5000K 3-Step MacAdam Ellipse	-	Square	11250lm (Typ)	2.7A	85°C	35V	119 lm/W	5.4A	80	120°	-	27.90mm L x 27.90mm W	1.37mm	26.50mm Dia
CHM-27-65-80-36-AA00-F2-3 LED COB CHM27 COOL WHITE SQUARE Luminus Devices Inc.	3,556	-	RFQ	데이터시트	Tray	CHM-27	Active	Chip On Board (COB)	White, Cool	6500K 3-Step MacAdam Ellipse	-	Square	11200lm (Typ)	2.7A	85°C	35V	119 lm/W	5.4A	80	120°	-	27.90mm L x 27.90mm W	1.37mm	26.50mm Dia
CHM-27-50-70-36-AA00-F2-3 LED COB CHM27 COOL WHITE SQUARE Luminus Devices Inc.	2,183	-	RFQ	데이터시트	Tray	CHM-27	Active	Chip On Board (COB)	White, Cool	5000K 3-Step MacAdam Ellipse	-	Square	11810lm (Typ)	2.7A	85°C	35V	125 lm/W	5.4A	70	120°	-	31.50mm L x 31.50mm W	1.37mm	26.50mm Dia
CHM-27-65-70-36-AA00-F2-3 LED COB CHM27 COOL WHITE SQUARE Luminus Devices Inc.	2,244	-	RFQ	데이터시트	Tray	CHM-27	Active	Chip On Board (COB)	White, Cool	6500K 3-Step MacAdam Ellipse	-	Square	11760lm (Typ)	2.7A	85°C	35V	124 lm/W	5.4A	70	120°	-	31.50mm L x 31.50mm W	1.37mm	26.50mm Dia
CHM-27-50-70-36-AB00-F2-3 LED COB Luminus Devices Inc.	2,671	-	RFQ	데이터시트	Tray	CHM-27	Not For New Designs	Chip On Board (COB)	White, Cool	5000K 3-Step MacAdam Ellipse	-	Square	11810lm (Typ)	2.7A	85°C	35V	125 lm/W	4A	70	120°	-	31.50mm L x 31.50mm W	1.37mm	26.50mm Dia
CHM-27-50-80-36-AB00-F2-3 LED COB Luminus Devices Inc.	2,622	-	RFQ	데이터시트	Tray	CHM-27	Not For New Designs	Chip On Board (COB)	White, Cool	5000K 3-Step MacAdam Ellipse	-	Square	11430lm (Typ)	2.7A	85°C	35V	121 lm/W	4A	80	120°	-	31.50mm L x 31.50mm W	1.37mm	26.50mm Dia
CHM-27-65-70-36-AB00-F2-3 LED COB Luminus Devices Inc.	3,097	-	RFQ	데이터시트	Tray	CHM-27	Not For New Designs	Chip On Board (COB)	White, Cool	6500K 3-Step MacAdam Ellipse	-	Square	11760lm (Typ)	2.7A	85°C	35V	124 lm/W	4A	70	120°	-	31.50mm L x 31.50mm W	1.37mm	26.50mm Dia
CHM-27-65-80-36-AB00-F2-3 LED COB Luminus Devices Inc.	3,621	-	RFQ	데이터시트	Tray	CHM-27	Not For New Designs	Chip On Board (COB)	White, Cool	6500K 3-Step MacAdam Ellipse	-	Square	11200lm (Typ)	2.7A	85°C	35V	119 lm/W	4A	80	120°	-	31.50mm L x 31.50mm W	1.37mm	26.50mm Dia
CHM-22-30-80-36-AC02-F2-2 LED COB CHM22 WARM WHITE SQUARE Luminus Devices Inc.	2,812	-	RFQ		Tray	CHM-22	Active	Chip On Board (COB)	White, Warm	3000K 2-Step MacAdam Ellipse	-	Square	7465lm (Typ)	1.92A	85°C	35V	111 lm/W	3.8A	80	120°	-	22.80mm L x 22.80mm W	1.37mm	22.00mm Dia
CHM-22-27-95-36-AC00-F2-2 LED COB CHM22 WARM WHITE SQUARE Luminus Devices Inc.	3,735	-	RFQ	데이터시트	Tray	CHM-22	Active	Chip On Board (COB)	White, Warm	2700K 2-Step MacAdam Ellipse	-	Square	5200lm (Typ)	1.92A	85°C	35V	77 lm/W	3.8A	95	120°	-	22.80mm L x 22.80mm W	1.37mm	22.00mm Dia
CHM-22-30-95-36-AC00-F2-2 LED COB CHM22 WARM WHITE SQUARE Luminus Devices Inc.	3,660	-	RFQ	데이터시트	Tray	CHM-22	Active	Chip On Board (COB)	White, Warm	3000K 2-Step MacAdam Ellipse	-	Square	5880lm (Typ)	1.92A	85°C	35V	88 lm/W	3.8A	95	120°	-	22.80mm L x 22.80mm W	1.37mm	22.00mm Dia
