LED 조명 - COB, 엔진, 모듈, 스트립

제조업체 부품 번호	재고 상태	가격	수량	데이터시트	Packaging	Series	ProductStatus	Type	Color	CCT(K)	Wavelength	Configuration	LuminousFlux@Current/Temperature	Current-Test	Temperature-Test	Voltage-Forward(Vf)(Typ)	Lumens/Watt@Current-Test	Current-Max	CRI(ColorRenderingIndex)	ViewingAngle	Features	Size/Dimension	Height	LightEmittingSurface(LES)
L219-2780006FV0C00 LED FLEX 6 X XF3014V 2700K 96MM Lumileds	2,864	-	RFQ	데이터시트	Strip	LUXEON XF-3014 CV	Obsolete	LED Engine	White, Warm	2700K	-	Linear Light Strip, Flexible	98lm (Typ)	45mA	50°C	24V	91 lm/W	-	80	-	-	96.00mm L x 10.00mm W	-	-
L219-3080006FV0C00 LED FLEX 6 X XF-3014V 3000K 96MM Lumileds	2,760	-	RFQ	데이터시트	Strip	LUXEON XF-3014 CV	Obsolete	LED Engine	White, Warm	3000K	-	Linear Light Strip, Flexible	102lm (Typ)	45mA	50°C	24V	94 lm/W	-	80	-	-	96.00mm L x 10.00mm W	-	-
L219-4080006FV0C00 LED FLEX 6 X XF-3014V 4000K 96MM Lumileds	3,208	-	RFQ	데이터시트	Strip	LUXEON XF-3014 CV	Obsolete	LED Engine	White, Neutral	4000K	-	Linear Light Strip, Flexible	112lm (Typ)	45mA	50°C	24V	104 lm/W	-	80	-	-	96.00mm L x 10.00mm W	-	-
L219-2780030FV0C00 LED FLEX 30X XF3014V 2700K 480MM Lumileds	3,761	-	RFQ	데이터시트	Strip	LUXEON XF-3014 CV	Obsolete	LED Engine	White, Warm	2700K	-	Linear Light Strip, Flexible	490lm (Typ)	225mA	50°C	24V	91 lm/W	-	80	-	-	480.00mm L x 10.00mm W	-	-
L219-3080030FV0C00 LED FLEX 30X XF3014V 3000K 480MM Lumileds	3,178	-	RFQ	데이터시트	Strip	LUXEON XF-3014 CV	Obsolete	LED Engine	White, Warm	3000K	-	Linear Light Strip, Flexible	510lm (Typ)	225mA	50°C	24V	94 lm/W	-	80	-	-	480.00mm L x 10.00mm W	-	-
L219-4080030FV0C00 LED FLEX 30X XF3014V 4000K 480MM Lumileds	2,609	-	RFQ	데이터시트	Strip	LUXEON XF-3014 CV	Obsolete	LED Engine	White, Neutral	4000K	-	Linear Light Strip, Flexible	560lm (Typ)	225mA	50°C	24V	104 lm/W	-	80	-	-	480.00mm L x 10.00mm W	-	-
L219-2780C06FV0000 LED FLEX 6 X XF-3014V 2700K 96MM Lumileds	3,512	-	RFQ	데이터시트	Tape & Reel (TR),Cut Tape (CT)	LUXEON XF-3014 CV	Obsolete	LED Engine	White, Warm	2700K	-	Linear Light Strip, Flexible	98lm (Typ)	45mA	50°C	24V	91 lm/W	-	80	-	-	96.00mm L x 10.00mm W	-	-
L219-3080C06FV0000 LED FLEX 6 X XF-3014V 3000K 96MM Lumileds	3,732	-	RFQ	데이터시트	Tape & Reel (TR),Cut Tape (CT)	LUXEON XF-3014 CV	Obsolete	LED Engine	White, Warm	3000K	-	Linear Light Strip, Flexible	102lm (Typ)	45mA	50°C	24V	94 lm/W	-	80	-	-	96.00mm L x 10.00mm W	-	-
L219-4080C06FV0000 LED FLEX 6 X XF-3014V 4000K 96MM Lumileds	2,124	-	RFQ	데이터시트	Tape & Reel (TR),Cut Tape (CT)	LUXEON XF-3014 CV	Obsolete	LED Engine	White, Neutral	4000K	-	Linear Light Strip, Flexible	112lm (Typ)	45mA	50°C	24V	104 lm/W	-	80	-	-	96.00mm L x 10.00mm W	-	-
LE B P2W-FZGZ-24-0-F00-T01 LED OSTAR PROJ 459NM BLUE ams-OSRAM USA Inc.	3,422	-	RFQ		Tray	OSRAM OSTAR	Obsolete	LED Module	Blue	-	459nm (452nm ~ 465nm)	Rectangle	21500mW (15000mW ~ 28000mW)	24A	25°C	3.55V	-	-	-	120°	-	27.00mm L x 15.50mm W	2.10mm	-
LE CG P2W-7U5V-1-0-F00-T01 LED OSTAR PROJ 600NM GREEN ams-OSRAM USA Inc.	2,739	-	RFQ	데이터시트	Tray	OSRAM OSTAR	Obsolete	LED Module	Green	-	550nm (500nm ~ 600nm)	Rectangle	7300lm (5600lm ~ 9000lm)	24A	25°C	3.55V	86 lm/W	-	-	130°	-	27.00mm L x 15.50mm W	2.10mm	-
CHM-9-27-90-36-XH00-F2-3 LED COB CHM9 WARM WHITE SQUARE Luminus Devices Inc.	3,430	-	RFQ		Tray	CHM-9	Obsolete	Chip On Board (COB)	White, Warm	2700K 3-Step MacAdam Ellipse	-	Square	1945lm (Typ)	720mA	85°C	36V	75 lm/W	1.05A	90	120°	-	19.00mm L x 19.00mm W	2.24mm	9.00mm Dia
CHM-9-30-90-36-XH00-F2-3 LED COB CHM9 WARM WHITE SQUARE Luminus Devices Inc.	2,931	-	RFQ		Tray	CHM-9	Obsolete	Chip On Board (COB)	White, Warm	3000K 3-Step MacAdam Ellipse	-	Square	2050lm (Typ)	720mA	85°C	36V	79 lm/W	1.05A	90	120°	-	19.00mm L x 19.00mm W	2.24mm	9.00mm Dia
CHM-9-40-90-36-XH00-F2-3 LED COB CHM9 NEUTRAL WHITE SQ Luminus Devices Inc.	2,365	-	RFQ		Tray	CHM-9	Obsolete	Chip On Board (COB)	White, Neutral	4000K 3-Step MacAdam Ellipse	-	Square	2195lm (Typ)	720mA	85°C	36V	85 lm/W	1.05A	90	120°	-	19.00mm L x 19.00mm W	2.24mm	9.00mm Dia
CHM-9-50-90-36-XH00-F2-3 LED COB CHM9 COOL WHITE SQUARE Luminus Devices Inc.	3,032	-	RFQ		Tray	CHM-9	Obsolete	Chip On Board (COB)	White, Cool	5000K 3-Step MacAdam Ellipse	-	Square	2270lm (Typ)	720mA	85°C	36V	88 lm/W	1.05A	90	120°	-	19.00mm L x 19.00mm W	2.24mm	9.00mm Dia
CHM-9-27-80-36-XH00-F1-3 LED COB 2700K 80CRI 36V SMD Luminus Devices Inc.	2,067	-	RFQ		Tray	CHM-9	Obsolete	Chip On Board (COB)	White, Warm	2700K 3-Step MacAdam Ellipse	-	Square	-	720mA	85°C	36V	-	1.05A	80	120°	-	19.00mm L x 19.00mm W	1.37mm	9.00mm Dia
CHM-9-27-80-36-XH00-F2-2 LED COB 2700K 80CRI 36V SMD Luminus Devices Inc.	3,236	-	RFQ		Tray	CHM-9	Obsolete	Chip On Board (COB)	White, Warm	2700K 2-Step MacAdam Ellipse	-	Square	2430lm (Typ)	720mA	85°C	36V	94 lm/W	1.05A	80	120°	-	19.00mm L x 19.00mm W	1.37mm	9.00mm Dia
CHM-9-27-80-36-XH00-F2-3 LED COB 2700K 80CRI 36V SMD Luminus Devices Inc.	3,981	-	RFQ		Tray	CHM-9	Obsolete	Chip On Board (COB)	White, Warm	2700K 3-Step MacAdam Ellipse	-	Square	2430lm (Typ)	720mA	85°C	36V	94 lm/W	1.05A	80	120°	-	19.00mm L x 19.00mm W	1.37mm	9.00mm Dia
CHM-9-27-90-36-XH00-F1-3 LED COB 2700K 90CRI 36V SMD Luminus Devices Inc.	2,198	-	RFQ		Tray	CHM-9	Obsolete	Chip On Board (COB)	White, Warm	2700K 3-Step MacAdam Ellipse	-	Square	-	720mA	85°C	36V	-	1.05A	90	120°	-	19.00mm L x 19.00mm W	1.37mm	9.00mm Dia
CHM-9-27-90-36-XH00-F2-2 LED COB 2700K 90CRI 36V SMD Luminus Devices Inc.	3,048	-	RFQ		Tray	CHM-9	Obsolete	Chip On Board (COB)	White, Warm	2700K 2-Step MacAdam Ellipse	-	Square	1845lm (Typ)	720mA	85°C	36V	71 lm/W	1.05A	90	120°	-	19.00mm L x 19.00mm W	1.37mm	9.00mm Dia
